詳細規格

Environment

• Operating Temperature -10 ~ +60 °C with 0.7 m/s airflow (MaxN mode)
• Operating Humidity 95% @ 40 °C (non-condensing)
• Vibration 3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis
• Shock 10G / 11ms

Mechanical

• Dimension (W x H x D) Core Module: 192 x 230 x 87 mm (7.55" x 9.05" x 3.43") Plus MIC-75M10: 192 x 230 x 111 mm (7.55" x 9.05" x 4.37")
• Weight 4.5 kg (9.9 lb)
• Installation Desktop / Wall mount

Certification

• EMC, Safety CB/UL/CE/FCC/BSMI/CCC (No RED certification)

Processor System

• CPU 8-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU, 2MB L2 + 4MB L3
• GPU 1792-core NVIDIA Ampere GPU with 56 Tensor Cores, Maximum Operating Frequency: 930 MHz
• Memory 32GB 256-bit LPDDR5 DRAM
• NVIDIA Jetson Series AGX Orin 32G
• Al Performance Reference Up to 200 TOPs

Expansion

• Mini PCIe 1 x mPCIe (Signal: PCIe + USB 2.0)
• M.2 1 x M.2 3052 (B-Key, Signal: USB)
• GMSL 2-ch GMSL2.0 with FAKRA connectorsV
• SIM 2 x Nano SIM slots

Storage

• M.2 1 x M.2 2280 (M-Key, NVMe, Signal: PCIe x4)
• SD Card 1 x Micro SD

Power

• Input 9 ~ 36 VDC, 16-4A
• Mode AT/ATX (Default AT)

I/O

• Ethernet 4 x 10/100/1000 Mbps (Optional PoE support, IEEE 802.3af/at)
• Display HDMI (Max. resolution 3840x2160 @ 60Hz)
• USB External: 2 x USB 3.2 Gen 2, 1 x USB 2.0 Internal: 1 x USB 2.0 (by pin header)
• OTG USB 1 x Micro USB
• Digital I/O 4-ch DI, 4-ch DO
• Serial Port 2 x RS-232/422/485 (On-board pin header)
• Power Switch 1 x Power ON/OFF Button

Expansion

• iModule (Optional) 1 x PCIe x8 (MIC-75M10-00A2)

BSP

• Jetpack Above 5.0
