EKI-2525-BE 5埠非管理型工業乙太網路交換器 (10/100Mbps)
  • 5-port 10/100Mbps Unmanaged Ethernet switch

    • 提供 5 個 MDI/MDI-X 自動跳線傳輸乙太網路埠
    • 支援 10/100Mbps 自動協調
    • 超薄緊湊型，支持導軌式/壁掛式安裝及IP30金屬外殼設計
    • 支援 12 ~ 48 VDC 備援電源輸入和 P-Fail 繼電器警報
    • 預約(案場規劃)或(軟硬整合)諮詢服務
    Certifications C1D2 5年保固(90X60) CE FCC_Class-A UL-Listed RoHS
    產品使用手冊 產品3D圖 技術資源下載

    (未含稅)
    加入購物車 直接結帳
    EKI-2525-BE
    EKI-2525-BE
    EKI-2525-BE
    加入購物車

    產品已加入購物車

    > 前往結帳

    週邊配件

    EKI-2525-BE

    主產品:EKI-2525-BE

    5埠非管理型工業乙太網路交換器 (10/100Mbps)
  • 5-port 10/100Mbps Unmanaged Ethernet switch

    • 週邊配件

    • POWER SUPPLY, DIN-rail Power Supply

      NT$4,090

    • POWER SUPPLY, Panel Mount Power Supply

      NT$3,390

    • POWER SUPPLY, Panel Mount Power Supply

      NT$3,790

    • A/D 100-240V10W 24V MDR DIN RAIL

      NT$293

    {{relatedTitle}}

    主產品 + {{numOfSelectedRelatedProducts}}週邊配件

    小計 {{subTotalStr}}

    加入購物車 直接結帳

    詳細規格

    General

    • Technology Ethernet
    • Power 12-48VDC
    • Mounting DIN, Panel
    • Temperature -10 to 60C
    • Ethernet Port Count 5
    • Unmanaged Yes

    Power

    • Power Consumption 2.88 W
    • Power Input (DC) 12 ~ 48 VDC
    • Power Connector Type 6-pin removable screw terminal
    • Power Input (AC) -
    • Power Input (PoE) -
    • Power Input (Battery) -
    • Redundant Dual Inputs Yes

    Protection

    • Reverse Polarity Present
    • Overload Current Present

    Environment

    • Temperature (Storage Range) -40 ~ 85°C (-40 ~ 185°F)
    • Temperature (Operating Range) -10 ~ 60°C (14 ~ 140°F)
    • Temperature (Min. Operating) -10°C (14°F)
    • Temperature (Max. Operating) 60°C (140°F)

    Mechanism

    • Enclosure (Metal) Yes
    • Dimensions (W x H x D) 30 x 120 x 95 mm (1.18'' x 4.72'' x 3.74)
    • IP Rating IP30
    • Weight -
    • Mounting (DIN-rail) Yes
    • Mounting (Pole Mount) -
    • Mounting (Rack Mount) -
    • Mounting (Wall) Yes
    • Mounting (Stack) -
    • Enclosure (Plastic) -
    • Mounting (Panel) -

    Ethernet Communication

    • RJ45 Transmission Speed 10/100Mbps
    • Ethernet Port Number 5
    • RJ45 Port Connector Type RJ45
    • RJ45 Transmission Distance 100 m
    • Fiber Port Interface -
    • Fiber Port Connector Type -
    • Fiber Transmission Distance -
    • Fiber Port Number -
    • Fiber Transmission Speed -

    Certification

    • Safety UL 60950-1
    • EMI CE, FCC Class A
    • EMS EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8

    * Port Configuration

    • Description 5 x 10/100Base-T(X)
    • Total Port Number 5

    Warranty

    • Warranty Period 5 years

    Product Category

    • Layer 2 - Unmanaged Switch Yes

    PoE Information

    • PoE Budget -
    • PoE Port Number -
    • PoE Output -
    • Support PoE No
