AIMB-U217DZ-FLA1E Intel^®Atom ™ E3950/E3940 品質控制 1.6 GHz UTX 工業主機板 帶 HDMI/eDP （LVDS）/DP++、4 個通信和 3 個局域網

詳細規格

Display

• LVDS -
• Controller Intel Gen9 LP
• Multiple Display Triple
• DDI (HDMI/DVI/DisplayPort) HDMI1.4b: 3840 x 2160 @ 30Hz, ƒƒDP1.2a: 4096 x 2160 @ 60Hz
• eDP* eDP supports up to up to 3840 x 2160@60 Hz

Form Factor

• Form Factor UTX

I/O

• COM Port 2 x RS-232 & 2 x RS-232 or 422 or 485
• GPIO 1, 16-bit GPIO
• TPM TPM 2.0
• USB3.0/2.0 4 USB3.0, 2 USB2.0 (Optional)
• CANBus 1.25 mm, 3-pin, Male type Wafer Box

Memory

• Technology DDR3L 1866 MHz
• Max. Capacity 8 GB
• Socket 1 x 204-pin SODIMM

Processor

• CPU Atom X7-E3950
• L2 Cache 2 MB
• BIOS AMI 128 Mbit SPI
• Frequency 1.6 GHz
• Core Number 4
• CPU TDP 9.5~12W

Storage

• SATA 1 x SATA III (Max. Data Transfer Rate 600 MB/s)
• eMMC 32GB

Operating System

• Microsoft Windows Yes

Environment

• Operational Temperature -20 ~ 70 °C (-4 ~ 158 °F) with 0.7m/s air flow
• Non-Operational Temperature -40~ 85° C
• Vibration Resistance 3.5 Grms (non OP)

Power

• Power Type ATX, AT
• Connector DC Jack

Ethernet

• Controller 3
• Connector RJ45 x 3 (3rd LAN Optional)
• Speed 10/ 100/ 1000 Mbps

Audio

• Audio Interface HD Audio
• CODEC Realtek ALC888S, High Definition Audio (HD)
• Connector 1 (Line Out)

Watchdog Timer

• WatchDog Timer Yes

Expansion

• Slot Type 1 full-size MiniPCIe + M.2 E key (Type: 2230)

Physical

• Construction with fanless design
• Weight 1.04 kg (1.72 lb), weight of total package
• Dimension (mm) 112x 137 mm (4.4" x 5.3")
