5 Year Warranty

PCI-1622B-DE 8 埠 RS-232/422/485 PCI 通信卡,帶浪湧和隔離

  • 符合PCI總線2.2標準
  • 速度高達 921.6 kbps,可實現極快的數據傳輸
  • 支援任何波特率設置
  • 8 個 RS-232 或 RS-232/422/485 埠
  • XR17V358 UART 帶 256 位元組先進先出
  • 支援的操作系統:Windows 7/8/10 和 Linux。
  • 預約(案場規劃)或(軟硬整合)諮詢服務
Certifications CE

已含稅
加入購物車 直接結帳

產品亮點

Advantech’s complete range of industrial communication cards, with more than 30 models, are ready for you to implement into your system. With industrial-grade certification and protection, Advantech’s communication cards are designed for field devices that use the RS-232/422/485 and CAN interfaces.

Feature Highlights
Various OS and Software Support
  • Latest OS support: Win7, Win10, and Linux
  • Provides utilities and code examples for testing purpose
Complete Protection
  • Electrostatic discharge (EDS), 15,000 VDC (air), 8,000 VDC (contact)
  • Surge, 1000 VDC
  • 3000 VDC isolation voltage


Adapted to Different Needs
  • Any baud rate (serial comm. card only)
  • Transmission speeds up to 1Mbps
I/O Card Quick Selector
View More

Advantech provides an online selector for you to easily choose the model you need, just click here:

Product Specifications
Dimensions
Unit: mm
PCI-1600 Series
PCIE-1600 Series
Inside the Box
Communication Card Series

詳細規格

General

  • Connectors 1 x DB62 female connector

General

  • Serial Port Count 8
  • Serial Type RS-232/422/485
  • Serial Connector DB62 Female
  • Bus Type PCI
