WISE-S251-A
All Images
2 Year Warranty

WISE-S251-A WISE-4200/WISE-4400 6DI/1RS-485 I/O Module

  • 6-ch Digital Input with RS-485
  • Supports 200Hz Counter Input (32-bit + 1-bit overflow)
  • Supports keep/discard counter value on power off
  • Supports inverted digital input status
產品使用手冊 產品3D圖 技術資源下載

(未含稅)
加入購物車 直接結帳
WISE-S251-A
加入購物車

產品已加入購物車

> 前往結帳

詳細規格

Digital Input*

  • Channels 6 (Dry Contact)
  • Keep/Discard Counter Value when Power Off Support
  • Inverted DI Status Support

Serial Communication

  • Ports* 1
  • Type* RS-485
  • Data Bits 7, 8
  • Stop Bits 1, 2
  • Parity None, Odd, Even
  • Baud Rate (bps) 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
  • Protocol* Modbus/RTU (Total 32 address by max. 8 instruction)

Digital Input

  • Supports Inverted DI Status* -
