UNO-220-P4N2AE Industrial Raspberry Pi 4 Gateway Kit with POE

  • Industrial-grade gateway kit provides RPi-ready solutions for rapid prototyping
  • Protects from dust accumulation and extreme temperatures
  • Industrial I/O board with additional RS-232/485 and GPIO ports
  • PoE functionality enables power support via an Ethernet cable
  • Battery-backed RTC for fail-safe time keeping
  • Built-in TPM provides hardware-based security for data protection
  • OS enables automatic system identification and configuration of GPIOs and drivers
  • Supports wall mounting and DIN-rail installation for industrial applications
  • LED indicators enable easy maintenance
  • 預約(案場規劃)或(軟硬整合)諮詢服務
Certifications CE CE CE CE
產品規格書 驅動程式 產品使用手冊 產品3D圖 技術資源下載

已含稅
加入購物車 直接結帳
UNO-220-P4N2AE
UNO-220-P4N2AE
UNO-220-P4N2AE
UNO-220-P4N2AE
加入購物車

產品已加入購物車

> 前往結帳

詳細規格

Hardware

  • Storage 1 x 8 GB Micro SD card
  • I/O 8 x GPIO
  • Watchdog Timer 1~255 s
  • Hardware Security TPM 2.0
  • Certification CE, FCC
  • Power Consumption 1.5 W @ 5 VDC
  • OS Support Raspbian

I/O Interface

  • Serial Ports 1 x RS-232/485 (Terminal Block)

Environment

  • Relative Humidity 10~95% RH (non-condensing)
  • Ingress Protection IP40
  • Operating Temperature 0~50 °C (32~122 °F)

Power Requirements

  • Output PoE+ Power PSE for 802.3at/802.3af PoE network

Mechanical

  • Enclosure Aluminum housing
  • Mounting Stand, Din-rail
  • Weight (Net) 0.5 kg (1.1 lb)
  • Dimension (W x H x D) 100 x 70 x 32 mm
