2 Year Warranty

ADAM-6017-D 8 通道 AI/DO 模組

Certifications CE RoHS FCC modbus MQTT icon_UL

已含稅
加入購物車 直接結帳

週邊配件

ADAM-6017-D

主產品:ADAM-6017-D

8 通道 AI/DO 模組

週邊配件

  • POWER SUPPLY, DIN-rail Power Supply

    NT$4,295
  • POWER SUPPLY, Panel Mount Power Supply

    NT$3,560
  • POWER SUPPLY, Panel Mount Power Supply

    NT$3,980

{{relatedTitle}}

主產品 + {{numOfSelectedRelatedProducts}}週邊配件

小計 {{subTotalStr}}

詳細規格

Analog Input

  • Channels 8
  • lnput Type V, mV, mA
  • Input Range 0~0.15 V, 0~0.5 V, 0~1 V, 0~5 V, 0~10 V, ±0.15 V, ±0.5 V , ±1 V, ±5 V, ±10 V, ±20 mA, 0~20 mA, 4~20 mA
  • Sampling Rates(S/s) 100 S/s (sum)
  • Resolution(Bits) 16-bit

General

  • Protocol Modbus/TCP, ASCII command, TCP/IP, UDP, HTTP, DHCP, MQTT, SNMP
  • Connectors 1 x RJ45, 1 x 13-pin plug-in screw terminal, 1 x 9-pin plug-in screw terminal

Communications

  • Interface Ethernet

Environment

  • Operating Temperature -40~70 °C (-40~158 °F)
  • Isolation Voltage 2,000 VDC

Isolated Digital Output

  • Channels 2
  • Output Type Sink
  • Output Voltage 0~30 VDC
  • Sink Current 100 mA max./channel

Power Requirements

  • Input Voltage 10~30 VDC
